Product Instruction：
Main Functions and Features
Micro-volume filling with high precision and efficiency to prevent costly overfilling
-Precise filling of micro volumes as Low as 30uL
-Filling accuracy better than ±1%
-Big flow rate up to 16mL/s
-High Efficiency up to 120 bottles/minutes/channel
7-inch high-resolution touchscreen has powerful functions, flexible configuration, and easy-to-use
-Intuitive graphic interface for a fantastic interactive experience
-Up to 500 recipes can be stored and recalled easily
-Three levels of user accesses(administrator, developer, operator), operation log, batch report( can be saved to USB flash drive or printed directly), and electronic signature, for GMP and FDA 21CFR Part 11 compliance
Pump head: PFH01(microliter pump head)、PFH02 (milliliter pump head)
Tubing: Silicone tubing and tubing kits
Filling volume: 1uL-99.99L
Filling accuracy: better than ±1%
Filling precision: CV<0.5%
Filling time: 0.1seconds-999.9hours
Filling cycle: 0-999999 (0 means unlimited)
Interval time: 0.1s-999.9s
Back suction parameter: 0-30
Working direction: Clockwise
Calibration: Manual input calibration, balance reading calibration or online ratio calibration, with volume or mass data
Display: 7 inch touch screen, Chinese or English can be set
Work mode: Single channel filling, multi-channel filling with the same parameters or individual parameters
Access management and password protection: Three levels of user accesses (administrator, developer, operator), each user can have an exclusive password
Parameter recipe: Up to 500 recipes can be stored and recalled easily on the PFC controller
Batch report: Up to 800 batch reports can be stored on the PFC controller, which can be saved to USB flash drive or printed directly
Communication control: RS485 interface, Modbus RTU protocol；or Ethernet interface, TCP/IP protocol as optional
External control input: Start the pump, emergency stop, disable channel
Output: 1 output for malfunction status
IP rating: IP32
Power supply: AC 100V-240V ，50/60Hz， 250W
Dimension（L*W*H）: 548mm×245mm×198mm（without pump head）
Weight of system: 3.5kg（without pump head）: 16.1kg（without pump head）
Dimension of controller (L*W*H）: 187mm×123mm×39mm
Weight of controler: 0.6kg
Working condition: Temperature: 5 – 40°C ，RH: ≤85%, no condensation
Storage and transportation condition: Temperature：-40 – 70°C，RH: ≤85%, no condensation
